Authelia + Traefik: SSO for self-hosted services without losing a weekend

Self-hosted SSO has a reputation for being a weekend ruiner. It is not. It is a four-hour job the first time, and a three-line add per new service after that. This essay is the deploy plan I wish I'd had in front of me on the Saturday morning I started. Part of the rig.

The goal, in one sentence

One browser login — a username, a password, a TOTP code — grants me access to Jellyfin, Immich, Nextcloud, Sonarr/Radarr, Home Assistant, the *arr stack, and anything else I put behind Traefik. No per-service credentials. No "which password was Jellyfin again."

The pieces

• Traefik 3 — reverse proxy, reads labels off containers, handles TLS via Let's Encrypt or internal Step-CA, supports ForwardAuth middleware for delegating auth to an external service.
• Authelia 4.38 — the external auth service. Handles the login page, sessions, 2FA, password file / LDAP backend. Lightweight Go binary.
• Redis — session storage for Authelia. Single small container.

That's the whole architecture. No Keycloak, no Authentik, no self-hosted Identity Provider empire. Authelia is the minimum viable thing that does the job.

The deploy plan — four hours, one Saturday

Hour 1 — Traefik

If you already run Traefik, skip this. If you don't: stand up a Traefik container with Docker socket mounted, a labels-based config, and your chosen TLS strategy. Mine uses Step-CA for internal certs and Let's Encrypt only for the two services I expose publicly.

services:
  traefik:
    image: traefik:v3.2
    restart: unless-stopped
    ports: ["80:80", "443:443"]
    volumes:
      - /var/run/docker.sock:/var/run/docker.sock:ro
      - ./traefik.yml:/etc/traefik/traefik.yml:ro
      - ./acme:/acme
    labels:
      - traefik.enable=true
      - traefik.http.routers.api.rule=Host(\`traefik.home\`)
      - traefik.http.routers.api.service=api@internal

Verify: hit https://traefik.home, see the dashboard, TLS green in the browser. If that works, you have a reverse proxy. Move on.

Hour 2 — Authelia

Authelia has three config pieces: the main YAML, the users database (a file or LDAP), and an access control policy. Starting config:

# configuration.yml
server:
  address: "tcp://:9091"

authentication_backend:
  file:
    path: /config/users_database.yml

access_control:
  default_policy: deny
  rules:
    - domain: "jellyfin.home"
      policy: one_factor
    - domain: "immich.home"
      policy: one_factor
    - domain: "sonarr.home"
      policy: two_factor
    - domain: "traefik.home"
      policy: two_factor

session:
  name: authelia_session
  secret: "$(openssl rand -hex 32)"
  expiration: 12h
  inactivity: 1h
  cookies:
    - domain: home
      authelia_url: "https://auth.home"

storage:
  local:
    path: /config/db.sqlite3
  encryption_key: "$(openssl rand -hex 32)"

notifier:
  filesystem:
    filename: /config/notifier.log

Three choices reflected here that matter:

• Default deny. Every service I add must explicitly be allowed. Better than "default allow, deny specific" — that's how people end up with admin panels accidentally exposed.
• Two-factor on admin-ish services (Traefik dashboard, Sonarr, Radarr). One-factor on consumer-ish services (Jellyfin, Immich) so my partner and in-law aren't fighting a TOTP app every night.
• Filesystem notifier for password-reset links during setup. In production I'll swap this for SMTP, but on first deploy it saves me SMTP debugging on day one.

Hour 3 — Wiring Traefik to Authelia

Add the ForwardAuth middleware in Traefik's dynamic config:

# traefik/dynamic.yml
http:
  middlewares:
    authelia:
      forwardAuth:
        address: http://authelia:9091/api/verify?rd=https://auth.home/
        trustForwardHeader: true
        authResponseHeaders:
          - Remote-User
          - Remote-Groups
          - Remote-Name
          - Remote-Email

Then every protected service gets one label:

labels:
  - traefik.enable=true
  - traefik.http.routers.jellyfin.rule=Host(\`jellyfin.home\`)
  - traefik.http.routers.jellyfin.middlewares=authelia@file

That's it. That's the contract. Add the middleware reference, hit the URL, Authelia's login page appears.

Hour 4 — User setup, TOTP, and the password file

Generate a bcrypt hash for each user:

docker run --rm authelia/authelia:4.38 \
  authelia crypto hash generate argon2 --password 'your-password-here'

Put the result in users_database.yml:

users:
  theo:
    displayname: "Theo Marren"
    password: "$argon2id$v=19$m=65536,t=3,p=4$..."
    email: [email protected]
    groups: ["admins"]
  partner:
    displayname: "Partner"
    password: "$argon2id$v=19$m=65536,t=3,p=4$..."
    email: [email protected]
    groups: ["household"]

First login at https://auth.home. Authelia prompts to set up TOTP; scan the QR with Aegis (or any TOTP app, not SMS). You are done.

The one thing that tripped me up

Jellyfin has its own auth and the forward-auth headers don't feed it automatically. I have two options:

1. Leave Jellyfin's own login in front of Authelia. Two logins. Ugly.
2. Use Authelia headers to auto-log-in to Jellyfin via the LDAP backend + Jellyfin's LDAP plugin. Nice. More moving parts.

I went with option 1 for now. My partner has her Jellyfin credentials saved in Safari — the Authelia login is extra but not painful.

The next essay will be about Step-CA

Authelia + Traefik closes the auth door. The next hole is that browsers still scream about self-signed certs on internal-only services. Step-CA fixes that — a private CA my household devices trust, automated certs via ACME. That's a separate weekend.

Context for the whole security layer: The self-hosting stack I actually use in 2026.
